Fuel cell forklift powered system Introduction Fuel cell forklift powered system Introduction

The proton exchange membrane fuel cell stack is a device for electrochemical reaction of hydrogen and oxygen to output electrical energy.It has the characteristics of high energy density and environment friendly. Fuel is gaseous Hydrogen, Oxidant is

Fuel cell forklift powered system Feature Fuel cell forklift powered system Feature
  • Low temperature oper...
  • Water cooling
  • Air does not get wet...
  • Quick start and dyna...
  • Fuel cell test laboratory
Product description Product parameters Product case

SGF developed two generations of 10kW fuel cell power system - SLHF-10 (A / B) for the CLASS II forklift, two for the balance of electric forklift and vertical forklift forklift , Tonnage is 1.5 tons and 2 tons. SLHF-10 series of products in the United States for more than 1000 hours of warehouse use test, test results proved that the divine manufacturing 10kW forklift fuel cell system, has reached the requirements and stable performance.

型号

SLHF-10(A/B)

系统最大功率

18kW (10 sec burst)

燃料电池功率

10kW

辅助电源

超级电容

系统输出电压

36V/48V DC

系统输出电流

0-500A

尺寸L*W*H(mm)

985*455*772(SLHF-10A)980*830*570(SLHF-10B)

重量

>900kg

燃料能量转化率

>50%

持续运行时间

4-6小时

燃料类型

液态氢

充氢所需时间

2-5 分钟(350Bar)

储氢量

>1.2Kg (350Bar)

充氢接口

SAE J-2600 H35

环境温度

-5℃~40

操作温度

50 ℃~80

相对湿度

095%

冷却方式

水冷

通讯方式

CAN

排放

水蒸气

电插头

Anderson SB-350

备注:上述数据仅供参考,根据客户要求开发设计。
