Fuel cell module Introduction Fuel cell module Introduction

No record

Fuel cell module Feature Fuel cell module Feature
  • Easy to integrate wi...
  • Electromagnetic comp...
  • Dust and other advan...
  • Automotive standard ...
  • Fuel cell module
Product description Product parameters Product case
SDF is based on the development of SL-C series of products, successfully developed a high-performance fuel cell stack module SL-CM series of products, power coverage of 0-40kW.The SL-CM series integrates CVM. Fully consider the hydrogen safety design, with high waterproof and dustproof, high electromagnetic compatibility, anti-vibration characteristics, can be used as a separate parts for the vehicle, but also easy to FCE. Applicable to passenger cars, passenger cars and logistics vehicles and other fields. SL-CM series products can be customized according to the different needs of customers, accept the following 40kW power.

技术参数

SL-CM-40kW

项目

参数

功率

40 kW

额定电压

114VDC

额定电流

348A

节数

185

重量

65kg

CVM通道

185

通讯

CAN

防水防尘

IP67

环境温度

-20~75

工作温度

55-75

低温储藏

-20℃(在实施吹扫基础上)

通风

需要外系统提供空气或者氮气气源

燃料

氢气浓度>95%*0-50kPa

空气

无增湿(0-50kPa,需要使用除尘除硫过滤器)

安全

内置氢气浓度报警(暂未配置二极管、继电器、电流传感器等)

应用场景

车载

*基于SAE J2719-2011
